Mine 2IN

INTRODUCING MINE2IN

Mine 2IN X-Ray is a medical handheld X-Ray system

Mine 2IN X-Ray is a medical handheld X-Ray system manufactured in India & offers utmost user-convenience and safety while offering high-quality images.

Mine 2IN Features

Portable

Easy to carry, as it is
lightweight-1.8kg only.

Minimized Radiation

It only uses 2mA current..

High-Quality Images

Image quality matches standard
X-ray’s even in lower radiations

Wireless

Easy to connect.

High Quality Image

Mine 2IN X-Ray is the best handheld X-Ray system designed to provide utmost user convenience and safety while offering high quality images.

Software Assistance

Optional Al software assists diagnosis of diseases using simple X-Ray images and clinical information. This system is based on hybrid artificial neutral network technology or lesion detection and disease classification. It also provides Al analyzed probability of having a given disease. It assists physicians to diagnose diseases based on the image.

Mine 2IN X-Ray System

Mine 2IN X-Ray is a medical handheld X-Ray system manufactured in India & offers utmost user-convenience and safety while offering high-quality images.

X-Ray Generator Mine 2IN
Detector DXD 17x17
Mine 2IN Wireless Remote Control
X-Ray Generator Stand
Laptop

SPECIFICATION

Mine 2IN X-Ray Generator

Input Power

X-ray Unit : DC 5-12V 2.1A
Battery Charger : AC 100-240V, 50Hz,1A

Output Power

140W Maximum

Power Supply

DC11.1V (Battery)

Adjustable Function

Only Exposure Time

Selectable exposure time

0.01sec.~ 1.3sec.

Tube KV/MA

70kV/2mA

Focal Spot Size

0.4mm

Weight

1.8kg

Digital Detector DXD

External Dimension And Weight

17 x 17, 3.2 kg / 14 x 17, 2.95 kg

MTF DQE

MTF @ 0.5lp/mm : (Typ.) 89%
DQE @ 0.1lp/mm : (Typ.) 72%

A/D Conversion / Data Output

16bit / 16bit

Cycle Time / Full Image

8 sec. / 3 sec.

Image Area

X-ray Sensitive Pixel :
3072 x 3072 pixels / 2500 x 3052 pixels

X-ray Sensitive Pixel :
430.08 x 430.08 mm / 350 x 427.28 mm

TFT Type

A-si

Scintillator

Csl

Pixel Size

140 m
